Spesifikasi Hytera BP518
| UMUM | |
| Rentang Frekuensi | VHF: 136-174 MHz, UHF: 400-470 MHz |
| Kapasitas Saluran | 256 |
| Kapasitas Zona | 4 |
| Saluran Per Zona | 16 |
| Jarak Spasi Saluran | 12.5kHz/20kHz/25kHz |
| Tegangan Operasional | 7.4V |
| Baterai | 1500mAh (Standar), 2000mAh (Opsional) |
| Daya Tahan Baterai | Analogue: 12 Jam (1500mAh), 16 Jam (2000mAh), Digital: 16 Jam (1500mAh), 22 Jam (2000mAh) |
| Berat (dengan antena & baterai) | 210g ±5%g |
| Dimensi (T x L x D) | 115X54.5X29.5mm |
| Bluetooth (Opsional) | BT 5.0 BLE+EDR |
| PENERIMA | |
| Sensitivitas | Digital: 0.1 BμV / BERS%, Analogue: 0.1 BμV (12dB SINAD) |
| Selektivitas Saluran Bersebelahan | TIA-603: 60dB@12.5kHz; 70dB@20/25kHz, ETSI: 60dB@12.5kHz; 70dB@20/25kHz |
| Intermodulasi | TIA-603: 70dB@12.5/20/25kHz, ETSI: 65dB@12.5/20/25kHz |
| Penolakan Respon Spontan | TIA-603: 70dB@12.5/20/25kHz, ETSI: 70dB@12.5/20/25kHz |
| Blokiran | TIA-603: B0dB, ETSI: 84dB |
| Hum dan Noise | 40dB@12.5kHz; 43dB@20kHz; 45dB@25kHz |
| Daya Keluaran Audio Dinilai | 1W |
| Distorsi Audio Dinilai | <3% |
| Respon Audio | +1 sampai -3dB |
| Emisi Spontan yang Dilakukan | <-57dBm |
| PEMANCAR | |
| Daya Keluaran RF | VHF: 5W/1W, UHF: 4W/1W |
| Modulasi FM | 11K0F3E@12.5kHz; 14K0F3E@20kHz; 16K0F3E@25kHz |
| Emisi yang Dilakukan/Dipancarkan | -36dBm < 1GHz; -30dBm > 1GHz |
| Pembatasan Modulasi | ±2.5kHz@12.5kHz; ±4.0kHz@20kHz; ±5.0kHz@25kHz |
| Hum & Noise FM | 40dB@12.5kHz; 43dB@20kHz; 45dB@25kHz |
| Daya Saluran Bersebelahan | 60dB@12.5kHz; 70dB@20/25kHz |
| LINGKUNGAN | |
| Suhu Operasional | -30°C hingga +60°C |
| Suhu Penyimpanan | -40°C hingga +85°C |
| ESD | IEC 61000-4-2 (Level 4) ±8kV (kontak); ±15kV (udara) |
| Perlindungan Debu & Air | IEC60529-IP54 (IP67 opsional) |
| Kelembaban | MIL-STD-810 G |
| Shock dan Getaran | MIL-STD-810 G |
